Introducing the L6202 - DMOS Full Bridge Driver

The L6202 from STMicroelectronics is a powerful and versatile full-bridge driver designed for motor control applications that demand high efficiency and reliability. This integrated circuit is capable of driving both windings of a bipolar stepper motor or bidirectionally control two DC motors.

Key Features

• Operating Supply Voltage: The L6202 operates from a supply voltage ranging from 12V to 48V, making it suitable for a variety of industrial applications.
• Output Current: It can deliver up to 1A per channel with peak current up to 2A, ensuring robust performance for a wide range of motor sizes.
• Efficient DMOS Output Stage: The device features a DMOS output stage with low RDS(on), which translates to reduced power dissipation and improved efficiency.
• Integrated Protection Features: Includes thermal shutdown, under-voltage lockout, and non-dissipative overcurrent protection, safeguarding the device and the motor under extreme conditions.
• Cross Conduction Protection: The L6202 has a patented circuitry that prevents shoot-through current, enhancing the reliability of the application.

Applications

The L6202 is ideal for a diverse range of applications, including:

• Stepper motor controllers
• DC motor controllers
• Robotics and automation systems
• Factory automation
• Process control

Design Support

STMicroelectronics provides comprehensive design support for the L6202, including detailed datasheets, application notes, and reference designs. This ensures that engineers can rapidly integrate the L6202 into their designs with confidence and achieve optimal performance.

With its robust design, integrated protections, and high current capability, the L6202 stands out as a superior choice for designers looking to create efficient and reliable motor control systems.

For more information on the L6202, visit the STMicroelectronics website or contact their support team for technical assistance.
