The VFR1112H-6B83A-TR is a surface-mount LED manufactured by Stanley Electric Co. This LED is designed for various indicator and display applications, offering a vibrant light output and a compact form factor suitable for densely populated circuit boards. Its robust construction ensures reliable performance in demanding environments.

Applications

• Backlighting for LCD displays: Provides illumination for small to medium-sized LCD screens.
• Indicator lights: Used in various electronic devices to indicate power status, activity, or alerts.
• Automotive lighting: Can be found in instrument panels, switches, and other interior lighting applications.
• Consumer electronics: Employed in appliances, audio equipment, and other consumer devices for visual feedback.
• Industrial equipment: Used in control panels, instrumentation, and other industrial applications.

Features

• Surface Mount Technology (SMT): Designed for automated assembly on printed circuit boards.
• Compact Size: Small footprint allows for high-density mounting.
• High Brightness: Provides a bright and easily visible light output.
• Wide Viewing Angle: Offers a wide viewing angle, ensuring visibility from various perspectives.
• Long Lifespan: Offers a long operational lifespan, reducing the need for frequent replacements.

Benefits

• Reduced Assembly Costs: SMT design enables automated assembly, lowering manufacturing expenses.
• Space Savings: Compact size allows for miniaturization of electronic devices.
• Improved Visibility: High brightness and wide viewing angle ensure clear indication, even in bright environments.
• Increased Reliability: Long lifespan reduces downtime and maintenance costs.
• Energy Efficiency: LEDs are known for their low power consumption, contributing to energy savings.

The VFR1112H-6B83A-TR typically operates at a forward voltage of around 2-3 volts and requires a forward current in the range of 20-30 milliamperes. The specific color and intensity of the emitted light can be verified in the datasheet, ensuring appropriate selection for the intended application. It is often supplied on tape and reel for automated pick-and-place assembly. Proper heat sinking may be required in high-power applications to ensure optimal performance and longevity of the LED. The package type and dimensions are critical for PCB layout and soldering considerations.
