SD560B Real Image SD560B real image13053
Same model may have multiple batches, images only for reference.
SD560B Real Image SD560B real image13053
SD560B Real Image SD560B real image13053
Same model may have multiple batches, images only for reference.

SD560B

Part No SD560B
Manufacturer SMC Diode Solutions
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 600V 5A SMB
Datasheet
SD560B Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr SMC Diode Solutions
Package Tape & Reel
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 600 V
Current - Average Rectified (Io) 5A
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 5 A
Speed Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 9 µA @ 600 V
Capacitance @ Vr, F 50pF @ 4V, 1MHz
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Supplier Device Package SMB (DO-214AA)
Operating Temperature - Junction -65°C ~ 175°C
Base Product Number SD560
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 664675-SD560B
Ultra Librarian 3D Model Ultra Librarian SD560B CAD Model

Description

The SD560B is a standard recovery diode with a voltage rating of 600V and an average rectified current of 5A.

  • Voltage Rating: 600V
  • Average Rectified Current: 5A
  • Application: Rectifier applications where fast recovery times are not critical
  • Forward Voltage Drop: 1.2V @ 5A
  • Reverse Leakage Current: 9µA @ 600V
  • Capacitance: 50pF @ 4V and 1MHz
  • Operating Temperature Range: -65°C to 175°C
  • Mounting: Surface mountable
  • Package: DO-214AA
  • Packaging: Tape and reel
  • Package Quantity: 3,000 pcs
  • Series: SD560 series from SMC Diode Solutions
  • Product Status: Active
