MBR10100 Real Image MBR10100 Real Image
Same model may have multiple batches, images only for reference.
MBR10100 Real Image MBR10100 Real Image
MBR10100 Real Image MBR10100 Real Image
Same model may have multiple batches, images only for reference.

MBR10100

Part No MBR10100
Manufacturer SMC Diode Solutions
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 100V TO220AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr SMC Diode Solutions
Package Tube
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 100 V
Voltage - Forward (Vf) (Max) @ If 850 mV @ 10 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 1 mA @ 100 V
Mounting Type Through Hole
Package / Case TO-220-2
Supplier Device Package TO-220AC
Operating Temperature - Junction -55°C ~ 150°C
Base Product Number MBR1010
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 220572-MBR10100
Ultra Librarian 3D Model Ultra Librarian MBR10100 CAD Model

Description

The MBR10100 is a fast recovery Schottky diode designed for rectification in electronic circuits.

  • Type: Fast recovery Schottky diode
  • Voltage Rating: 100V
  • Application: High-speed switching and low forward voltage drop
  • Package: TO-220-2
  • Mounting: Through-hole
  • Manufacturer: SMC Diode Solutions
  • Status: Active
  • Standard Package: 50 pieces
  • Alternative Diodes: DSS10-01A, MBR1090 C0G, and MBR1090HC0
