DB153 Real Image
Same model may have multiple batches, images only for reference.

DB153

Part No DB153
Manufacturer SMC Diode Solutions
Catalog Bridge Rectifiers
Description BRIDGE RECT 1P 200V 1.5A DB-M / Bridge Rectifier Single Phase Standard 200 V Through Hole DB-M
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr SMC Diode Solutions
Package Tube
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 200 V
Current - Average Rectified (Io) 1.5 A
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 1.5 A
Current - Reverse Leakage @ Vr 5 µA @ 200 V
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case 4-EDIP (0.321", 8.15mm)
Supplier Device Package DB-M
Base Product Number DB153
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 916793-DB153
Ultra Librarian 3D Model Ultra Librarian DB153 CAD Model

Description

The 916793-DB153 is a bridge rectifier diode designed for general-purpose applications.

  • Product Name: 916793-DB153
  • Diode Type: Single-phase
  • Maximum Forward Voltage Drop: 1.1V @ 1.5A
  • Maximum Reverse Leakage Current: 5μA @ 200V
  • Peak Reverse Voltage: 200V
  • Temperature Range: -55°C to 150°C
  • Mounting: Through-hole
  • Package: 4-EDIP
  • Manufacturer: SMC Diode Solutions
  • Series: DB153
  • Status: Currently active
  • REACH: Affected
  • ECCN: EAR99
