DB105 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr SMC Diode Solutions
Package Tube
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 600 V
Current - Average Rectified (Io) 1 A
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 1 A
Current - Reverse Leakage @ Vr 5 µA @ 600 V
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case 4-EDIP (0.321", 8.15mm)
Supplier Device Package DB-M
Base Product Number DB105
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 106329-DB105
Ultra Librarian 3D Model Ultra Librarian DB105 CAD Model

Description

DB105 - Single Phase Bridge Rectifier

With a peak reverse voltage of 600V, the DB105 bridge rectifier is designed to provide seamless AC/DC conversion. This device ensures minimal power loss and can handle an average rectified current of up to 1A, making it a versatile component in electronic systems.

  • Applications/Projects:
    • Battery backup systems
    • Motor control circuits
    • Lighting control panels
  • Features and Benefits:
    • High efficiency in AC to DC conversion
    • Superior thermal conductivity for better heat dissipation
    • Durable construction for long service life
  • Additional Details:
    • Surge Overload Rating: 50A
    • Temperature Range: -55°C to +150°C
    • Compact design for reduced board space usage
