The SiTime SIT8002AC-43-33E-25 is a programmable oscillator from the SiTime SiT8002 series. These oscillators are known for their high performance, small size, and excellent reliability. The part number breakdown suggests the following: 'AC' may indicate specific operating voltage and temperature characteristics, '43' might designate specific configuration options or performance characteristics, '33E' possibly implies certain supply voltage and stability parameters, and '25' indicates an output frequency of 25 MHz. This oscillator is designed to provide a stable and precise clock signal for various electronic applications.

Applications

• Consumer electronics
• Industrial control systems
• Networking equipment
• Embedded systems
• FPGA and PLD clocking

Features

• Frequency: 25 MHz
• Supply Voltage: 3.3V
• High frequency stability
• Compact form factor
• Low power consumption
• Wide operating temperature range
• Programmable for customized applications

Benefits

• Provides a highly accurate and stable clock signal, improving system performance.
• Enables compact designs due to its small size.
• Offers flexibility through programmability, allowing customization for specific application requirements.
• Reduces power consumption, contributing to energy efficiency.
• Ensures reliable operation in harsh environments because of its wide temperature range.

The SiT8002 series oscillators utilize MEMS (Micro-Electro-Mechanical Systems) technology, which offers advantages over traditional quartz oscillators in terms of size, reliability, and robustness. This oscillator is commonly used in applications where precise timing is critical, such as data communication, signal processing, and embedded systems. Its low jitter and high stability ensure clean clock signals, minimizing errors and improving overall system accuracy.

Specifications:

• Frequency Stability: Typically ±20 ppm to ±50 ppm (depending on configuration)
• Operating Temperature Range: -40°C to +85°C
• Supply Voltage: 3.3V
• Output Signal: CMOS
• Package: Typically 2.5 x 2.0 mm or smaller
