PC900V0NSZXF Real Image PC900V0NSZXF real image
Same model may have multiple batches, images only for reference.
PC900V0NSZXF Real Image PC900V0NSZXF real image
PC900V0NSZXF Real Image PC900V0NSZXF real image
Same model may have multiple batches, images only for reference.

PC900V0NSZXF

Part No PC900V0NSZXF
Manufacturer Sharp Microelectronics
Catalog Optoisolators - Logic Output
Description OPTOISO 5KV OPEN COLLECTOR 6DIP
Datasheet
PC900V0NSZXF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Sharp Microelectronics
Packaging Tube/Rail
Status Obsolete(EOL)
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 5000Vrms
Input Type DC
Output Type Open Collector
Channel Output Current 50mA
Propagation Delay tpLH / tpHL (Max) 6μs, 3μs
Rise and Fall Time 100ns, 50ns
Forward Voltage 1.1V
Continuous forward current- Max 50mA
Supply Voltage - Operating 3 V to 15 V
Temperature Range - Operating -25°C to 85°C
Mounting Through Hole
Case / Package 6-DIP
Win Source Part Number 026437-PC900V0NSZXF
Family Name PC900V
Introduction Date July 28, 2005
ECCN EAR99
Country of Origin Japan
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PC900V0NSZXF CAD Model

Description

It is an obsolete (EOL) product, but it is still in demand due to its unique features.

  • Package: 6-DIP
  • Isolation Voltage: 5000Vrms
  • Temperature Range: -25°C to 85°C
  • Application: general-purpose
  • Compliance: halogen-free standards
