PC845XJ0000F Real Image
Same model may have multiple batches, images only for reference.

PC845XJ0000F

Part No PC845XJ0000F
Manufacturer Sharp Microelectronics
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 5KV 4CH DARLINGTON 16DIP / Optocoupler DC-IN 4-CH Darlington DC-OUT 16-Pin PDIP Sleeve
Datasheet
PC845XJ0000F Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Sharp Microelectronics
Packaging Tube
Part Status Obsolete(EOL)
Number of Channels 4
Voltage - Isolation 5000Vrms
Current Transfer Ratio (Minimum) 600% @ 1mA
Rise / Fall Time (Typ) 60μs, 53μs
Input Type DC
Output Type Darlington
Output Voltage MAX 35V
Output Current per Channel 80mA
Voltage - Forward (Vf) (Typ) 1.2V
Current - DC Forward (If) (Maximum) 50mA
Vce Saturation (Maximum) 1V
Operating Temperature Range -30°C ~ 100°C
Mounting Style Through Hole
Package 16-DIP
Manufacturer Package 16-DIP
Win Source Part Number 791445-PC845XJ0000F
Popularity Medium
Supply and Demand Status Limited
Family Name PC845
Introduction Date August 07, 2005
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian PC845XJ0000F CAD Model

Description

The Sharp Microelectronics PC845XJ0000F is an obsolete (EOL) product with a medium popularity in the market. The Win Source Part Number of this product is 791445-PC845XJ0000F and it comes in a 16-DIP package with an output type of Darlington and a voltage isolation of 5000Vrms.
