PC457L0NIP0F Real Image PC457L0NIP0F real image4461 PC457L0NIP0F real image4462
Same model may have multiple batches, images only for reference.
PC457L0NIP0F Real Image PC457L0NIP0F real image4461 PC457L0NIP0F real image4462
PC457L0NIP0F Real Image PC457L0NIP0F real image4461 PC457L0NIP0F real image4462
Same model may have multiple batches, images only for reference.

PC457L0NIP0F

Part No PC457L0NIP0F
Manufacturer Sharp Microelectronics
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV TRANSISTOR 5-SMD / Optocoupler DC-IN 1-CH Transistor With Base DC-OUT 5-Pin Mini-Flat T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Sharp Microelectronics
Packaging Reel - TR
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 19% @ 16mA
Maximum DC Current Transfer Ratio 50% @ 16mA
Switching Turn-On and Turn-Off Time 200ns, 400ns
Input Type DC
Output Type Transistor
Maximum Output Voltage 20V
Channel Output Current 8mA
Forward Voltage 1.7V
Continuous forward current- Max 25mA
Temperature Range - Operating -55°C to 85°C
Mounting SMD (SMT)
Case / Package 5-MFP
Win Source Part Number 026432-PC457L0NIP0F
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name PC457L
Introduction Date July 28, 2005
ECCN EAR99
Country of Origin China, Indonesia, Japan
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian PC457L0NIP0F CAD Model

Description

The Sharp Microelectronics PC457L0NIP0F is a high-quality optoisolator transistor output device that is ideal for use in a wide range of electronic applications.

  • Forward Voltage: 1.7V
  • Isolation Voltage: 3750Vrms
  • DC Current Transfer Ratio (Min): 19% @ 16mA
  • DC Current Transfer Ratio (Max): 50% @ 16mA
  • Switching Turn-On Time: 200ns
  • Switching Turn-Off Time: 400ns
  • Package: 5-MFP
  • Halogen-Free Compliant: Yes
