Products specifications Report Issue?

Categories Isolators
Manufacturer Sharp Microelectronics
Packaging Reel - TR
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 3750Vrms
Input Type DC
Output Type Open Collector
Channel Output Current 50mA
Propagation Delay tpLH / tpHL (Max) 6μs, 3μs
Rise and Fall Time 100ns, 50ns
Forward Voltage 1.1V
Continuous forward current- Max 50mA
Supply Voltage - Operating 3 V to 15 V
Temperature Range - Operating -25°C to 85°C
Mounting SMD (SMT)
Case / Package 5-MFP
Win Source Part Number 026429-PC400J00000F
Family Name PC400
Introduction Date February 24, 1997
ECCN EAR99
Country of Origin Indonesia
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PC400J00000F CAD Model

Description

The Sharp Microelectronics PC400J00000F is an isolator with a single channel output and an open collector output type.

  • Forward Voltage: 1.1V
  • Propagation Delay (tpLH): 6μs
  • Propagation Delay (tpHL): 3μs
  • Mounting Type: SMD (SMT)
  • Isolation Voltage: 3750Vrms
  • Rise Time: 100ns
  • Fall Time: 50ns
  • Channel Output Current: 50mA
  • Market Availability: Open Market
  • Supply and Demand Status: Sufficient
