PC3H7DJ0000F Real Image PC3H7DJ0000F Real Image
Same model may have multiple batches, images only for reference.
PC3H7DJ0000F Real Image PC3H7DJ0000F Real Image
PC3H7DJ0000F Real Image PC3H7DJ0000F Real Image
Same model may have multiple batches, images only for reference.

PC3H7DJ0000F

Part No PC3H7DJ0000F
Manufacturer Sharp Microelectronics
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 2.5KV TRANS 4-MINI-FLAT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Sharp Microelectronics
Packaging Reel - TR
Number of Channels 1
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 120% @ 1mA
Maximum DC Current Transfer Ratio 240% @ 1mA
Rise and Fall Time 4μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 200mV
Temperature Range - Operating -30°C to 100°C
Mounting SMD (SMT)
Case / Package 4-Mini-Flat
Win Source Part Number 102103-PC3H7DJ0000F
Family Name PC3H7
Introduction Date October 26, 1995
ECCN EAR99
Country of Origin Japan
Halogen Free Unknown
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian PC3H7DJ0000F CAD Model

Description

The Sharp Microelectronics PC3H7DJ0000F is an optoelectronics component with a transistor output type.

  • Maximum Output Voltage: 80V
  • Channel Output Current: 50mA
  • Popularity: high
  • Package/Case: 4-Mini-Flat
  • Mounting Technology: SMD (SMT)
  • Operating Temperature Range: -30°C to 100°C
  • Minimum DC Current Transfer Ratio: 120%
  • Maximum DC Current Transfer Ratio: 240%
