L512 Crydom Co.
Same model may have multiple batches, images only for reference.

L512

Part No L512
Manufacturer Sensata-Crydom
Catalog TVS - Thyristors
Description MODULE SCR/DIODE 25A 240VAC PCB
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Thyristors - SCRs - Modules
Mfr Sensata-Crydom
Series L
Package Bulk
Product Status Not For New Designs
Structure Bridge, Single Phase - SCRs/Diodes (Layout 1)
Number of SCRs, Diodes 2 SCRs, 2 Diodes
Voltage - Off State 600 V
Voltage - Gate Trigger (Vgt) (Max) 3 V
Current - Gate Trigger (Igt) (Max) 100 mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 300A @ 60Hz
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Through Hole
Package / Case Module
Standard Package 10 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.30.0080
California Prop 65 Warning Information
Win Source Part Number 611612-L512
Ultra Librarian 3D Model Ultra Librarian L512 CAD Model

Description

The 611612-L512 is a thyristor module from the L series, designed for use in discrete semiconductor products.

  • Voltage Off State: 600V
  • Voltage Gate Trigger: 3V
  • Current Gate Trigger: 100mA
  • Current Non-Repetitive Surge: 300A @ 60Hz
  • Layout: bridge, single-phase with 2 SCRs and 2 diodes
  • Mounting: through hole
  • Package: bulk
  • Operating Temperature: -40°C to 125°C
  • Manufacturer: Sensata-Crydom
