UCLAMP3301H.TCT Semtech Corporation UCLAMP3301H.TCT real image UCLAMP3301H.TCT label picture
Same model may have multiple batches, images only for reference.
UCLAMP3301H.TCT Semtech Corporation UCLAMP3301H.TCT real image UCLAMP3301H.TCT label picture
UCLAMP3301H.TCT Semtech Corporation UCLAMP3301H.TCT real image UCLAMP3301H.TCT label picture
Same model may have multiple batches, images only for reference.

UCLAMP3301H.TCT

Part No UCLAMP3301H.TCT
Manufacturer Semtech Corporation
Catalog TVS - Diodes
Description TVS DIODE 3.3VWM 8VC SOD523
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Semtech Corporation
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 3.3V (Max)
Minimum Breakdown Voltage 3.5V
Max Clamping Voltage 8V
Peak Pulse Current(Ippm) 5A (8/20μs)
Power Dissipation - Pd 40W
Applications General Purpose
Capacitance @ Frequency 25pF @ 1MHz
Temperature Range - Operating -55°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package SOD-523
Win Source Part Number 035870-UCLAMP3301H.TCT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Computers & Computer Peripherals, Consumer Electronics, Sensing & Instrumentation, Audio, Portable Devices, Industrial
Ultra Librarian 3D Model Ultra Librarian UCLAMP3301H.TCT CAD Model

Description

The Semtech Corporation UCLAMP3301H.TCT is a zener type electronic component designed for general purpose applications.

  • Type: Zener
  • Application: General Purpose
  • Capacitance: 25pF @ 1MHz
  • Case/Package: SOD-523
  • Stand-off Voltage: 3.3V (Max)
  • Minimum Breakdown Voltage: 3.5V
  • Maximum Clamping Voltage: 8V
  • Peak Pulse Current: 5A (8/20μs)
  • Power Dissipation: 40W
  • Mounting Technology: SMD (SMT)
  • Supply and Demand Status: Sufficient
  • Commonly Used In: Computers and computer peripherals, consumer electronics, sensing and instrumentation, audio, and portable devices.
