Same model may have multiple batches, images only for reference.

RCLAMP7534P.TNT

Name: RCLAMP7534P.TNT
Brand: Semtech Corporation
SKU: 508307
Availability: InStock
Rating: 4.91 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	RCLAMP7534P.TNT
Manufacturer	Semtech Corporation
Catalog	TVS - Diodes
Description	TVS DIODE 5VWM 25VC SGP2010N5
Datasheet	RCLAMP7534P.TNT Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Circuit Protection
Manufacturer	Semtech Corporation
Packaging	Reel - TR
Status	Active
Type	Steering (Rail to Rail)
Unidirectional Channels	4
STAND-OFF Voltage (Vwm)	5V (Max)
Minimum Breakdown Voltage	6.5V
Max Clamping Voltage	25V
Peak Pulse Current(Ippm)	4A (8/20μs)
Power Line Protection	Yes
Applications	Ethernet, HDMI
Capacitance @ Frequency	0.19pF @ 1MHz
Temperature Range - Operating	-40°C to 85°C (TJ)
Mounting	SMD (SMT)
Case / Package	SGP2010N5
Win Source Part Number	1091652-RCLAMP7534P.TNT
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian RCLAMP7534P.TNT CAD Model

Alternative Products

Description

The RClamp7534P.TNT is a steering (rail to rail) type IC manufactured by Semtech Corporation.

Type: Steering (rail to rail)
Channels: 4
Package: SGP2010N5
Mounting: Surface-mounted
Applications: Ethernet and HDMI
Protection: Power line protection
Capacitance: 0.19pF @ 1MHz
STAND-OFF Voltage (Vwm): 5V (Max)
Minimum Breakdown Voltage: 6.5V
Maximum Clamping Voltage: 25V
Peak Pulse Current(Ippm): 4A (8/20μs)
Temperature Range: -40°C to 85°C (TJ)
Popularity: Medium
Supply and Demand Status: Balanced
