RCLAMP0554S.TCT Real Image RCLAMP0554S.TCT real image5017
Same model may have multiple batches, images only for reference.
RCLAMP0554S.TCT Real Image RCLAMP0554S.TCT real image5017
RCLAMP0554S.TCT Real Image RCLAMP0554S.TCT real image5017
Same model may have multiple batches, images only for reference.

RCLAMP0554S.TCT

Part No RCLAMP0554S.TCT
Manufacturer Semtech Corporation
Catalog TVS - Diodes
Description TVS DIODE 5VWM 15VC SOT23-6
Datasheet
RCLAMP0554S.TCT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Semtech Corporation
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 5V (Max)
Minimum Breakdown Voltage 6V
Max Clamping Voltage 15V
Peak Pulse Current(Ippm) 25A (8/20μs)
Power Dissipation - Pd 375W
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 5pF @ 1MHz
Temperature Range - Operating -55°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-6
Win Source Part Number 027246-RCLAMP0554S.TCT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RCLAMP0554S.TCT CAD Model

Description

The Semtech Corporation steering rail-to-rail protection component with Win Source Part Number 027246-RCLAMP0554S.TCT is a high-quality electronic component designed for general-purpose applications.

  • Mounting: SMD (SMT)
  • Channels: four unidirectional
  • Protection: power line
  • Capacitance: 5pF @ 1MHz
  • Operating Temperature Range: -55°C to 125°C (TJ)
  • Case/Package: SOT-23-6
  • STAND-OFF Voltage: 5V (Max)
  • Minimum Breakdown Voltage: 6V
  • Maximum Clamping Voltage: 15V
  • Peak Pulse Current(Ippm): 25A (8/20μs)
  • Power Dissipation: 375W
  • Popularity: medium
