Same model may have multiple batches, images only for reference.
3403.0282.23 Real Image
Same model may have multiple batches, images only for reference.

3403.0282.23

Part No 3403.0282.23
Manufacturer Schurter Inc.
Catalog Fuses
Description FUSE BRD MNT 6.3A 277VAC/125VDC / 6.3 A 277 V AC 125 V DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, Square End Block
Datasheet
3403.0282.23 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Fuses
Mfr SCHURTER Inc.
Series UMT-H
Package Tape & Reel
Mounting SMD (SMT)
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating (Amps) 6.3 A
Voltage Rating - AC 277 V
Voltage Rating - DC 125 V
Response Time Slow Blow
Package / Case 2-SMD, Square End Block
Breaking Capacity @ Rated Voltage 1.5kA
Melting I2t 165
Approval Agency CQC, cURus, VDE
Temperature Range - Operating -55°C ~ 125°C
Dimension 0.606" L x 0.211" W x 0.211" H (15.40mm x 5.35mm x 5.35mm)
Base Product Number 3403.0282
MSL Level Vendor Undefined
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.10.0040
Other Names 486-3567-6,486-3567-1,486-3567-2,3403.0282.23-ND
Standard Package 1,500
Win Source Part Number 1230123-3403.0282.23
Ultra Librarian 3D Model Ultra Librarian 3403.0282.23 CAD Model

Description

The Schurter Inc. 3403.0282.23 is a UMT-H board mount (cartridge style excluded) fuse in a 2-SMD, square end block package. The voltage rating for AC is 277V, and for DC is 125V. It has a slow blow response time and a breaking capacity of 1.5kA at rated voltage. The melting I2t is 165. The temperature range for operating is -55°C to 125°C. This product is a part of the circuit protection > fuses category. The current rating is 6.3A. The REACH status is REACH affected.
