3402.0017.22 Real Image
Same model may have multiple batches, images only for reference.

3402.0017.22

Part No 3402.0017.22
Manufacturer Schurter Inc.
Catalog Fuses
Description FUSE BOARD MNT 5A 63VAC/VDC 2SMD / 5 A 63 V AC 63 V DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, J-Lead
Datasheet
3402.0017.22 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Fuses
Mfr SCHURTER Inc.
Series OMF 63
Package Tape & Reel
Mounting SMD (SMT)
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating (Amps) 5 A
Voltage Rating - AC 63 V
Voltage Rating - DC 63 V
Response Time Fast Blow
Package / Case 2-SMD, J-Lead
Breaking Capacity @ Rated Voltage 50A
Melting I2t 2.9
Approval Agency cURus
Temperature Range - Operating -55°C ~ 125°C
Dimension 0.291" L x 0.122" W x 0.102" H (7.40mm x 3.10mm x 2.60mm)
Base Product Number 3402.0017
MSL Level Vendor Undefined
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.10.0040
Other Names 486-3936-6,486-3936-2,486-3936-1,3402.0017.22-ND
Standard Package 750
Win Source Part Number 995192-3402.0017.22
Ultra Librarian 3D Model Ultra Librarian 3402.0017.22 CAD Model

Description

The SCHURTER Inc. OMF 63 series board mount fuse is designed to protect electronic circuits from overcurrent and short circuits.

  • Manufacturer: SCHURTER Inc.
  • Series: OMF 63
  • Fuse Type: Board Mount
  • Response Time: Fast Blow
  • Breaking Capacity: 50A @ 63V AC/DC
  • Current Rating: 5A
  • Melting I2t: 2.9
  • Packaging: Tape and reel
  • Package/Case: 2-SMD J-lead
  • Operating Temperature Range: -55°C to 125°C
  • Dimensions: 0.291" L x 0.122" W x 0.102" H (7.40mm x 3.10mm x 2.60mm)
  • ECCN: EAR99 compliant
  • REACH: Unaffected
  • HTSUS Classification: 8536.10.0040
