Same model may have multiple batches, images only for reference.
DD100KB160 Real Image
Same model may have multiple batches, images only for reference.

DD100KB160

Part No DD100KB160
Manufacturer SanRex Corporation
Catalog Diodes, Rectifiers - Arrays
Description DIODE MODULE 1600V 100A
Datasheet
DD100KB160 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr SanRex Corporation
Package Tray
Product Status Active
Diode Configuration 1 Pair Series Connection
Technology Standard
Voltage - DC Reverse (Vr) (Max) 1600 V
Current - Average Rectified (Io) (per Diode) 100A
Voltage - Forward (Vf) (Max) @ If 1.35 V @ 320 A
Speed Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 30 mA @ 1600 V
Operating Temperature - Junction -40°C ~ 150°C
Mounting Type Chassis Mount
Package / Case Module
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 584251-DD100KB160
Ultra Librarian 3D Model Ultra Librarian DD100KB160 CAD Model

Description

The SanRex Corporation diode array is a high-quality product designed for rectifier applications.

  • Manufacturer: SanRex Corporation
  • Recovery Speed: Standard
  • Current Capability: High
  • Voltage Rating: 1600V
  • Mounting Type: Chassis Mount
  • Operating Temperature Range: -40°C to 150°C
  • Status: Active
