Name: SSW-148-02-G-D
Brand: Samtec Inc.
SKU: 1288904
Availability: InStock
Rating: 4.85 (5 reviews)

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr	Samtec Inc.
Series	SSW
Package	Bulk
Connector Type	Receptacle
Contact Type	Forked
Style	Board to Board or Cable
Number of Positions	96
Number of Positions Loaded	All
Pitch - Mating	0.100" (2.54mm)
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	20.0µin (0.51µm)
Insulation Color	Black
Insulation Height	0.335" (8.51mm)
Contact Length - Post	0.194" (4.93mm)
Temperature Range - Operating	-55°C ~ 125°C
Material Flammability Rating	UL94 V-0
Contact Finish - Post	Gold
Current Rating (Amps)	4.7A per Contact
Insulation Material	Liquid Crystal Polymer (LCP)
Contact Shape	Square
Contact Material	Phosphor Bronze
Contact Finish Thickness - Post	3.00µin (0.076µm)
Base Product Number	SSW-148
Other Names	SAM1214-48
Standard Package	1
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Win Source Part Number	1288904-SSW-148-02-G-D
Ultra Librarian 3D Model	Ultra Librarian SSW-148-02-G-D CAD Model

Description

The SSW series connector is a rectangular connector from Samtec Inc. with 96 positions.

Style: Board-to-board or Cable
Pitch: 0.100" (2.54mm)
Row Spacing: 0.100" (2.54mm)
Connector Type: Receptacle
Contact: Forked
Positions Loaded: All
Termination: Solder
Fastening Type: Push-Pull
Contact Material: Phosphor Bronze
Contact Finish (Mating): Gold (20.0µin (0.51µm))
Contact Finish (Post): Gold (3.00µin (0.076µm))
Insulation Material: Liquid Crystal Polymer (LCP)
Insulation Color: Black
Insulation Height: 0.335" (8.51mm)
Contact Length (Post): 0.194" (4.93mm)
Temperature Range: -55°C ~ 125°C
Current Rating: 4.7A per contact
