The SSW series connector is a receptacle type connector with 78 positions loaded in two rows.

• Connector Type: Receptacle
• Positions: 78
• Rows: 2
• Fastening Type: Push-Pull
• Contact Type: Forked
• Voltage Rating: -
• Current Rating: 4.7A per contact
• Contact Material: Phosphor Bronze
• Insulation Material: Liquid Crystal Polymer (LCP)
• Flammability Rating: UL94 V-0
• Contact Finish Mating: Gold, 20.0µin (0.51µm)
• Contact Finish Post: Gold, 3.00µin (0.076µm)
• Pitch-Mating: 0.100" (2.54mm)
• Row Spacing: 0.100" (2.54mm)
• Contact Length Post: 0.104" (2.64mm)
• Insulation Height: 0.335" (8.51mm)
• Style: Board to board or cable
• Temperature Range: -55°C to 125°C
