Same model may have multiple batches, images only for reference.
SSW-111-02-G-D Real Image
Same model may have multiple batches, images only for reference.

SSW-111-02-G-D

Part No SSW-111-02-G-D
Manufacturer Samtec Inc.
Catalog Rectangular Connectors
Description CONN RCPT 22POS 0.1 GOLD PCB
Datasheet
SSW-111-02-G-D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr Samtec Inc.
Series SSW
Package Bulk
Product Status Active
Connector Type Receptacle
Contact Type Forked
Style Board to Board or Cable
Number of Positions 22
Number of Positions Loaded All
Pitch - Mating 0.100" (2.54mm)
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 20.0µin (0.51µm)
Insulation Color Black
Insulation Height 0.335" (8.51mm)
Contact Length - Post 0.194" (4.93mm)
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Gold
Current Rating (Amps) 4.7A per Contact
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Contact Material Phosphor Bronze
Contact Finish Thickness - Post 3.00µin (0.076µm)
Base Product Number SSW-111
Standard Package 1 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
California Prop 65 Warning Information
Win Source Part Number 935150-SSW-111-02-G-D
Ultra Librarian 3D Model Ultra Librarian SSW-111-02-G-D CAD Model

Description

The SSW series header receptacle is a versatile rectangular connector designed for various applications. It features a pitch of 0.100" (2.54mm) and has 22 positions.

  • Series: SSW
  • Positions: 22
  • Pitch: 0.100" (2.54mm)
  • Contact Type: Forked
  • Fastening Type: Push-Pull
  • Insulation Color: Black
  • Insulation Material: Liquid Crystal Polymer (LCP)
  • Contact Finish (Mating): Gold (20.0µin / 0.51µm)
  • Contact Finish (Post): Gold
  • Insulation Height: 0.335" (8.51mm)
  • Operating Temperature: -55°C to 125°C
  • Manufacturer: Samtec Inc.
  • Status: Active
  • California Prop 65: Compliant
