The SSQ series of connectors from Samtec Inc. offers an 86-position receptacle with forked contacts.

• Positions: 86
• Contact Type: forked
• Rows: two rows
• Positions Loaded: all positions
• Fastening Type: push-pull
• Termination: solder
• Contact Material: phosphor bronze
• Voltage: 465VAC and 655VDC
• Insulation Material: liquid crystal polymer (LCP)
• Insulation Color: black
• Contact Finish (Mating): gold with a thickness of 20.0µin (0.51µm)
• Contact Finish (Post): gold with a thickness of 3.00µin (0.076µm)
• Pitch-Mating: 0.100" (2.54mm)
• Row Spacing-Mating: 0.100" (2.54mm)
• Contact Length-Post: 0.394" (10.00mm)
• Insulation Height: 0.335" (8.51mm)
• Temperature Range: -55°C to 125°C
