The SFMC-126-02-H-D is a fine-pitch micro header manufactured by Samtec, designed for high-density board-to-board connections. It belongs to Samtec's SFMC series, known for its compact size and reliable performance in demanding applications.

Applications

• High-Density Interconnects: Used in applications requiring a large number of connections in a small space.
• Board-to-Board Connections: Provides a reliable connection between two printed circuit boards.
• Medical Devices: Suitable for medical equipment where space is a premium.
• Industrial Automation: Employed in industrial control systems requiring robust connectivity.
• Data Communications Equipment: Used in servers, routers, and other networking devices.

Features

• Fine Pitch: Allows for high-density connections with a small footprint.
• Dual Row Configuration: Maximizes the number of contacts in a given space.
• 26 Positions per Row: Provides a total of 52 contacts.
• Samtec Tiger Eye™ Contacts: Ensures a reliable and durable connection.
• High Temperature Material: Allows for use in high-temperature environments.
• Surface Mountable: Designed for automated assembly processes.

Benefits

• Space Optimization: Fine pitch design enables more components to be placed on the board.
• Reliable Connection: Tiger Eye™ contacts ensure a secure and long-lasting connection.
• Automated Assembly: Surface mount design simplifies the manufacturing process.
• High Contact Density: Dual row configuration maximizes the number of connections in a small area.
• Robust Performance: High-temperature material ensures reliable operation in demanding conditions.
• Durable Construction: Withstands harsh environments and frequent mating cycles.

Additional Details

The SFMC-126-02-H-D connector is manufactured using high-quality materials to ensure optimal performance and longevity. The 'H' designation typically indicates a specific housing height, and the 'D' signifies a dual-row configuration. It is often used in conjunction with Samtec's cable assemblies for a complete interconnect solution. This connector provides a compact, reliable, and high-density interconnect solution for a wide range of applications. The '02' likely refers to a specific plating option or other manufacturing detail. Mates with FFSD, FFTP, and other compatible series from Samtec.
