The 1292372-SQT-108-01-F-D-RA is a rectangular connector header, receptacle, female socket manufactured by Samtec Inc.

• Series: SQT
• Positions: 16
• Contact Type: Forked
• Positions Loaded: All
• Rows: 2
• Termination: Solder
• Fastening Type: Push-pull
• Contact Material: Phosphor Bronze
• Voltage Rating: Not specified
• Standard Package: 34
• Insulation Material: Liquid Crystal Polymer (LCP)
• Style: Board to board or cable
• Pitch (Mating): 0.079" (2.00mm)
• Contact Finish (Mating): Gold
• Contact Finish Thickness (Mating): Flash
• Contact Finish (Post): Tin
• Insulation Color: Black
• Mounting Type: Through hole, Right Angle
• Row Spacing (Mating): 0.079" (2.00mm)
• Contact Length (Post): 0.090" (2.29mm)
• Insulation Height: 0.157" (4.00mm)
• Contact Shape: Square
• Temperature Range (Operating): -55°C ~ 125°C
• MSL Level: 1
• Current Rating: 5.1A per contact
• HTSUS: 8536.69.4040
• Other names: SAM12885, SQT-108-01-F-D-RA
