This Samtec Inc. SLW rectangular connector is a high-quality product with a Win Source Part Number of 1292549-SLW-137-01-S-D.

• Win Source Part Number: 1292549-SLW-137-01-S-D
• Series: SLW
• Connector Type: Receptacle
• Contact Type: Forked
• Positions: 74
• Positions Loaded: All
• Rows: Two
• Termination: Solder
• Fastening Type: Push-Pull
• Contact Material: Phosphor Bronze
• Voltage Rating: Not Provided
• Mated Stacking Heights: 6.09mm
• Ingress Protection: No
• Material Flammability Rating: Not Provided
• Insulation Material: Polyester, Glass Filled
• Style: Board to Board
• Pitch - Mating: 0.100" (2.54mm)
• Contact Finish - Mating: Gold
• Contact Finish Thickness - Mating: 30.0µin (0.76µm)
• Contact Finish - Post: Tin
• Contact Finish Thickness - Post: Not Provided
• Insulation Color: Black
• Mounting Type: Through-Hole
• Row Spacing - Mating: 0.100" (2.54mm)
• Contact Length - Post: 0.115" (2.92mm)
• Insulation Height: 0.180" (4.57mm)
• Contact Shape: Square
• Temperature Range: -55°C ~ 125°C
• MSL Level: Not Applicable
• HTSUS: 8536.69.4040
• Base Product Number: SLW-137
