IP5-06-01-L-S-RA1-TR Real Image
Same model may have multiple batches, images only for reference.

IP5-06-01-L-S-RA1-TR

Part No IP5-06-01-L-S-RA1-TR
Manufacturer Samtec Inc.
Catalog Coaxial Connectors (RF)
Description 4.00 MM ISORATE 50 OHM HIGH-ISO / Connector Plug, Female Socket 50Ohm Surface Mount, Right Angle Solder
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Coaxial Connectors (RF)
Mfr Samtec Inc.
Series ISORATE® IP5
Package Tape & Reel
Connector Type Plug, Female Socket
Contact Termination Solder
Impedance 50Ohm
Mounting Type Surface Mount, Right Angle
Frequency - Max 9.5 GHz
Number of Ports 6
Housing Color Black
Center Contact Material Copper Alloy
Body Material Polyamide (PA), Nylon
Center Contact Plating Gold
Dielectric Material Liquid Crystal Polymer (LCP)
Temperature Range - Operating -55°C ~ 125°C
Voltage Rating 190 V
Insertion Loss 3dB
Base Product Number IP5-06
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4010
Other Names 612-IP5-06-01-L-S-RA1-TRCT,IP5-06-01-L-S-RA1-TR-ND,612-IP5-06-01-L-S-RA1-TRDKR,612-IP5-06-01-L-S-RA1-TR
Standard Package 150
Win Source Part Number 961636-IP5-06-01-L-S-RA1-TR
Ultra Librarian 3D Model Ultra Librarian IP5-06-01-L-S-RA1-TR CAD Model

Description

The 961636-IP5-06-01-L-S-RA1-TR is a coaxial connector with a plug and female socket connector type.

  • Voltage Rating: 190 V
  • Frequency Max: 9.5 GHz
  • Number of Ports: 6
  • Impedance: 50Ohm
  • Mounting Type: Surface Mount, Right Angle
  • Operating Temperature Range: -55°C to 125°C
  • Body Material: Polyamide (PA), Nylon
  • Center Contact Material: Copper Alloy
  • Center Contact Plating: Gold
  • Housing Color: Black
  • Series: ISORATE® IP5
