FTSH-110-01-L-DV Real Image
Same model may have multiple batches, images only for reference.

FTSH-110-01-L-DV

Part No FTSH-110-01-L-DV
Manufacturer Samtec Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 20POS 1.27MM  /  Connector Header Surface Mount 20 position 0.050" (1.27mm)
Datasheet
FTSH-110-01-L-DV Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Samtec Inc.
Series FTSH
Package Bulk
Connector Type Header, Cuttable
Contact Type Male Pin
Pitch - Mating 0.050" (1.27mm)
Number of Positions 20
Number of Rows 2
Row Spacing - Mating 0.050" (1.27mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Unshrouded
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.120" (3.05mm)
Insulation Height 0.099" (2.51mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 10.0µin (0.25µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Liquid Crystal Polymer (LCP)
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3.4A per Contact
Base Product Number FTSH-110
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names SAM1161-10
Standard Package 1
Win Source Part Number 1180291-FTSH-110-01-L-DV
Ultra Librarian 3D Model Ultra Librarian FTSH-110-01-L-DV CAD Model

Description

The FTSH series male pin header connector is a 2-row, 20-position connector designed for board-to-board or cable-to-board applications from Samtec Inc.

  • Fastening Type: Push-pull
  • Insulation Material: Liquid crystal polymer (LCP)
  • Contact Material: Phosphor bronze
  • Mating Contact Finish: Gold plated
  • Contact Finish Thickness: 10.0μin (0.25μm)
  • Current Rating: 3.4A per contact
  • Operating Temperature Range: -55°C to 125°C
  • Shrouding: Unshrouded
  • Mating Pitch: 0.050" (1.27mm)
  • Contact Shape: Square
  • Contact Length: 0.120" (3.05mm)
  • Packaging: Bulk
  • Termination: Soldering
