Same model may have multiple batches, images only for reference.
FTSH-105-01-L-DV-K-P Real Image
Same model may have multiple batches, images only for reference.

FTSH-105-01-L-DV-K-P

Part No FTSH-105-01-L-DV-K-P
Manufacturer Samtec Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 10POS 1.27MM / Connector Header Surface Mount 10 position 0.050" (1.27mm)
Datasheet
FTSH-105-01-L-DV-K-P Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Samtec Inc.
Series FTSH
Package Tube
Connector Type Header, Cuttable
Contact Type Male Pin
Pitch - Mating 0.050" (1.27mm)
Number of Positions 10
Number of Rows 2
Row Spacing - Mating 0.050" (1.27mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Unshrouded
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.120" (3.05mm)
Insulation Height 0.099" (2.51mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 10.0µin (0.25µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Liquid Crystal Polymer (LCP)
Features Keying Shroud, Pick and Place
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3.4A per Contact
Base Product Number FTSH-105
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names SAM9076,FTSH-105-01-L-DV-K-P-ND
Standard Package 92
Win Source Part Number 965990-FTSH-105-01-L-DV-K-P
Ultra Librarian 3D Model Ultra Librarian FTSH-105-01-L-DV-K-P CAD Model

Description

The FTSH-105-01-L-DV-K-P is a rectangular connector header manufactured by Samtec Inc.

  • Positions: 10
  • Features: Keying Shroud and Pick and Place
  • Connector Type: Male Pin
  • Loading: All Positions Loaded
  • Termination: Solder
  • Fastening: Push-Pull
  • Mounting: SMD (SMT)
  • Pitch-Mating: 0.050" (1.27mm)
  • Contact Finish-Mating: Gold
  • Contact Finish-Mating Thickness: 10.0µin (0.25µm)
  • Application: Board to Board or Cable
  • Popularity: Low
  • REACH: Unaffected
  • Temperature Range: -55°C ~ 125°C
