The WM8805GEDS/RV is a high-performance S/PDIF transceiver designed by Cirrus Logic. It's designed to transmit and receive S/PDIF (Sony/Philips Digital Interface Format) audio data, commonly used in digital audio applications. This transceiver is often employed in devices requiring reliable and high-quality digital audio transmission and reception.

Applications:

• AV receivers
• Digital audio workstations (DAWs)
• Sound cards
• Digital mixing consoles
• High-end audio equipment

Features:

• S/PDIF transmitter and receiver
• Low jitter performance
• Supports sample rates up to 192kHz
• Integrated PLL (Phase-Locked Loop)
• Flexible clocking options
• CMOS compatible inputs and outputs

Benefits:

• High-Quality Digital Audio: Ensures reliable and accurate transmission and reception of digital audio signals.
• Low Jitter: Minimizes timing errors, resulting in cleaner and more accurate audio reproduction.
• Versatile Compatibility: Supports a wide range of audio formats and sample rates.
• Simplified Design: Integrated PLL reduces the need for external components, simplifying the design process.
• Flexible Integration: Flexible clocking options allow for easy integration into various system designs.

The WM8805GEDS/RV is designed to provide a low-jitter S/PDIF interface, ensuring high-quality digital audio transmission. The integrated PLL helps to minimize jitter and timing errors, contributing to a cleaner and more accurate audio signal. This transceiver supports a wide range of audio formats and sample rates, ensuring compatibility with various audio sources and systems. The flexible clocking options allow for easy integration into various system designs. The CMOS compatible inputs and outputs simplify interfacing with other digital components.

Specifications:

• Interface: S/PDIF
• Sample Rate: Up to 192 kHz
• Jitter: Low
• Power Consumption: Low
