DW-12-09-G-S-200-LL

Name: DW-12-09-G-S-200-LL
Brand: Samtec Inc.
SKU: 990928
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	DW-12-09-G-S-200-LL
Manufacturer	Samtec Inc.
Catalog	Rectangular Connectors
Description	CONN HDR 12POS 0.1 STACK T/H / 12 Position Header Spacer Connector 0.100" (2.54mm) Gold Through Hole
Datasheet	DW-12-09-G-S-200-LL Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Mfr	Samtec Inc.
Series	Flex Stack, DW
Package	Bulk
Number of Positions	12
Pitch	0.100" (2.54mm)
Number of Rows	1
Length - Overall Pin	0.730" (18.542mm)
Length - Post (Mating)	0.420" (10.668mm)
Length - Stack Height	0.200" (5.080mm)
Length - Tail	0.110" (2.794mm)
Mounting Type	Through Hole
Termination	Solder
Contact Finish - Post (Mating)	Gold
Contact Finish Thickness - Post (Mating)	10.0µin (0.25µm)
Color	Black
Base Product Number	DW-12-09
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Standard Package	1
Win Source Part Number	990928-DW-12-09-G-S-200-LL
Ultra Librarian 3D Model	Ultra Librarian DW-12-09-G-S-200-LL CAD Model

Alternative Products

Description

The Flex Stack DW series board-to-board rectangular connector is a reliable solution for your electronic connector needs.

Positions: 12
Pitch: 0.100" (2.54mm)
Applications: connectors, interconnects, and board spacers
Color: black
Termination: solder
Mounting Type: through-hole
Post Length: 0.420" (10.668mm)
Stack Height: 0.200" (5.080mm)
Tail Length: 0.110" (2.794mm)
Contact Finish (Post Mating): gold
Contact Finish Thickness: 10.0µin (0.25µm)
Packaging: bulk
Standard Package: 1
Pin Length: 0.730" (18.542mm)
REACH: unaffected
