BBD-109-T-B

Name: BBD-109-T-B
Brand: Samtec Inc.
SKU: 1033998
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	BBD-109-T-B
Manufacturer	Samtec Inc.
Catalog	Rectangular Connectors
Description	CONN HEADER VERT 18POS 2.54MM / Connector Header Through Hole 18 position 0.100" (2.54mm)
Datasheet	BBD-109-T-B Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr	Samtec Inc.
Series	BBD
Package	Tube
Connector Type	Header
Contact Type	Male Pin
Pitch - Mating	0.100" (2.54mm)
Number of Positions	18
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Number of Positions Loaded	All
Style	Board to Board
Shrouding	Unshrouded
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Length - Mating	0.125" (3.18mm)
Contact Length - Post	0.125" (3.18mm)
Overall Contact Length	0.585" (14.86mm)
Insulation Height	0.335" (8.51mm)
Contact Shape	Circular
Contact Finish - Mating	Tin
Contact Finish - Post	Nickel
Insulation Material	Polyester, Glass Filled
Temperature Range - Operating	-55°C ~ 125°C
Insulation Color	Black
Contact Finish Thickness - Post	50.0µin (1.27µm)
Base Product Number	BBD-109
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Standard Package	25
Win Source Part Number	1033998-BBD-109-T-B
Ultra Librarian 3D Model	Ultra Librarian BBD-109-T-B CAD Model

Description

The BBD series of rectangular connectors by Samtec Inc. is a reliable product that is designed to meet the needs of modern electronic devices.

Win Source Part Number: 1033998-BBD-109-T-B
Connector Type: Header
Positions: 18
Contact Type: Male Pin
Loaded: All positions
Termination: Soldered
Fastening Type: Push-Pull
Insulation Material: Polyester, Glass Filled
Color: Black
Mounting Type: Through Hole
Shrouded: Unshrouded
Contact Shape: Circular
Temperature Range: -55°C to 125°C
