Same model may have multiple batches, images only for reference.
SCA8VT78HAL9V06DEP Real Image
Same model may have multiple batches, images only for reference.

SCA8VT78HAL9V06DEP

Part No SCA8VT78HAL9V06DEP
Manufacturer Samsung
Catalog LED Lighting - White
Description LED LH309A WARM WHITE 3000K SMD / LED Lighting series White, Warm 3000K 26V 150mA 120° 2020 (5050 Metric)
Datasheet
SCA8VT78HAL9V06DEP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics>LED Lighting - White
Mfr Samsung Semiconductor, Inc.
Series LH309A
Package Tape & Reel
Product Status Obsolete
Color White, Warm
CCT (K) 3000K
Flux @ 85°C, Current - Test 495lm (445lm ~ 545lm)
Current - Test 150mA
Voltage - Forward (Vf) (Typ) 26V
Lumens/Watt @ Current - Test 127 lm/W
CRI (Color Rendering Index) 80
Current - Max 250mA
Viewing Angle 120°
Mounting SMD (SMT)
Package / Case 2020 (5050 Metric)
Supplier Device Package 12-CSP
Dimension 0.197" L x 0.197" W (5.00mm x 5.00mm)
Height - Seated (Max) 0.016" (0.40mm)
Thermal Resistance of Package 1.2°C/W
Other Names 1510-1605,1510-1605-2,1510-1605,1510-1605-1,1510-1605-6
Standard Package 1,000
MSL Level 2A (4 Weeks)
ECCN EAR99
HTSUS 8541.41.0000
Win Source Part Number 1240151-SCA8VT78HAL9V06DEP
Ultra Librarian 3D Model Ultra Librarian SCA8VT78HAL9V06DEP CAD Model

Description

The LH309A series from Samsung Semiconductor, Inc. is a high-quality LED lighting solution that produces a warm white light.

  • Viewing Angle: 120 degrees
  • Forward Voltage: 26V
  • Maximum Current: 250mA
  • Thermal Resistance: 1.2 degrees Celsius per watt
  • Color Temperature: 3000K @ a current test of 150mA
  • Flux: 495 lumens @ 85 degrees Celsius
  • Package or Case: 2020 (5050 Metric)
  • Packaging: Tape and Reel
  • Application: optoelectronics applications such as LED lighting
