Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Capacitors - Aluminum Electrolytic Capacitors
Mfr Rubycon
Series YXH
Package Bulk
Product Status Active
Capacitance 470 µF
Tolerance ±20%
Voltage - Rated 63 V
ESR (Equivalent Series Resistance) -
Lifetime @ Temp. 10000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Ratings -
Applications General Purpose
Ripple Current @ Low Frequency 621.5 mA @ 120 Hz
Ripple Current @ High Frequency 1.13 A @ 100 kHz
Impedance 77 mOhms
Lead Spacing 0.295" (7.50mm)
Size / Dimension 0.630" Dia (16.00mm)
Height - Seated (Max) 0.866" (22.00mm)
Surface Mount Land Size -
Mounting Type Through Hole
Package / Case Radial, Can
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 1358167-63YXH470MEFC16X20
Ultra Librarian 3D Model Ultra Librarian 63YXH470MEFC16X20 CAD Model

Description

The Rubycon 1358167-63YXH470MEFC16X20 is an aluminum electrolytic capacitor designed for general-purpose applications.

  • Capacitance: 470 µF
  • Voltage Rating: 63 V
  • Temperature Range: -40°C to 105°C
  • Lifetime: 10,000 hours @ 105°C
  • Package: Radial, can
  • Size: 0.630" diameter and a height of 0.866"
  • Lead Spacing: 0.295" (7.50mm)
  • Mounting: Through-hole
  • Ripple Current (Low Frequency): 621.5 mA @ 120 Hz
  • Ripple Current (High Frequency): 1.13 A @ 100 kHz
