Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Capacitors - Aluminum Electrolytic Capacitors
Mfr Rubycon
Series YXJ
Package Bulk
Product Status Active
Capacitance 3300 µF
Tolerance ±20%
Voltage - Rated 35 V
ESR (Equivalent Series Resistance) -
Lifetime @ Temp. 10000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Ratings -
Applications General Purpose
Ripple Current @ Low Frequency 2.76 A @ 120 Hz
Ripple Current @ High Frequency 3.45 A @ 100 kHz
Impedance 19 mOhms
Lead Spacing 0.295" (7.50mm)
Size / Dimension 0.630" Dia (16.00mm)
Height - Seated (Max) 1.319" (33.50mm)
Surface Mount Land Size -
Mounting Type Through Hole
Package / Case Radial, Can
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 1377458-35YXJ3300M16X31.5
Ultra Librarian 3D Model Ultra Librarian 35YXJ3300M16X31.5 CAD Model

Description

The Rubycon 1377458-35YXJ3300M16X31.5 is a high-capacity aluminum electrolytic capacitor with a capacitance of 3300 µF and a voltage rating of 35 V from Rubycon.

  • Application: General-Purpose
  • Temperature Range: -40°C to 105°C
  • Size: 16.00mm (Diameter), 33.50mm (Height)
  • Capacitance: 3300 µF
  • Voltage Rating: 35V
  • Tolerance: ±20%
  • Ripple Current (Low Frequency): 2.76 A @ 120 Hz
  • Ripple Current (High Frequency): 3.45 A @ 100 kHz
  • Lifetime: 10000 hours @ 105°C
  • Mounting Type: Through-Hole
  • Package: Radial, Can
  • Series: YXJ
  • Product Status: Active
  • REACH: Unaffected
  • ECCN: EAR99
