Same model may have multiple batches, images only for reference.

100MXC1000MEFCSN25X25

Name: 100MXC1000MEFCSN25X25
Brand: Rubycon
SKU: 1380470
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	100MXC1000MEFCSN25X25
Manufacturer	Rubycon
Catalog	Aluminum Capacitors
Description	CAP ALUM 1000UF 20% 100V SNAP / 1000 µF 100 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 3000 Hrs @ 105°C
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Capacitors>Aluminum Electrolytic Capacitors
Mfr	Rubycon
Series	MXC
Package	Bulk
Product Status	Not For New Designs
Capacitance	1000 µF
Tolerance	±20%
Voltage - Rated	100 V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	3000 Hrs @ 105°C
Temperature Range - Operating	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	1.47 A @ 120 Hz
Ripple Current @ High Frequency	1.6905 A @ 10 kHz
Lead Spacing	0.394" (10.00mm)
Size / Dimension	0.984" Dia (25.00mm)
Height - Seated (Max)	1.063" (27.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can - Snap-In
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8532.22.0040
Standard Package	200 pcs
Win Source Part Number	1380470-100MXC1000MEFCSN25X25
Ultra Librarian 3D Model	Ultra Librarian 100MXC1000MEFCSN25X25 CAD Model

Description

The MXC Aluminum Electrolytic Capacitor is a high-quality component designed for general-purpose applications from Rubycon.

Capacitance: 1000 μF
Capacitance Tolerance: ±20 percent
Voltage Rating: 100 V
Ripple Current (Low Frequency): 1.47 A @ 120 Hz
Ripple Current (High Frequency): 1.6905 A @ 10 kHz
Lifetime: 3000 hours @ 105°C
Polarization: Polarized
Package: Radial, Snap-In
REACH Compliant: Unaffected
ECCN: EAR99
HTSUS Code: 8532.22.0040
Moisture Sensitivity Level: 1 (unlimited)
