Products specifications

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Reel package
Diode Configuration 1 Pair Series Connection
Diode Type Standard
Voltage - DC Reverse (Vr) (Maximum) 80V
Current - Average Rectified (Io) (per Diode) 100mA
Voltage - Forward (Vf) (Maximum) @ If 1.2V @ 100mA
Current - Reverse Leakage @ Vr 10nA @ 20V
Operating Temperature - Junction 150°C (Maximum)
Mounting SMD
Package SC-70, SOT-323
Manufacturer Package UMD3
Win Source Part Number 772398-DA380UT106
Popularity Medium
Supply and Demand Status Balance
Family Name DA380U
Introduction Date October 13, 2011
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2020
Ultra Librarian 3D Model Ultra Librarian DA380UT106 CAD Model

Description

The DA380UT106 is a rectifier diode array manufactured by Rohm Semiconductor, consisting of two diodes in a single package. These diodes are designed for high-speed switching applications.

Applications:

  • High-speed rectification
  • Freewheeling diodes in inductive loads
  • Reverse polarity protection
  • DC-DC converters
  • AC-DC power supplies

Features:

  • Dual diode configuration
  • High-speed switching
  • Low forward voltage drop
  • Surface Mount Device (SMD)
  • Compact package

Benefits:

  • Reduced component count
  • Improved circuit efficiency
  • Minimized power dissipation
  • Simplified board layout
  • Suitable for automated assembly

Technical Specifications:

The DA380UT106 contains two rectifier diodes in a common cathode configuration. Key electrical characteristics include reverse voltage (VR), forward current (IF), and forward voltage drop (VF). The device is designed for surface mount applications. For precise voltage, current, and temperature ratings, consult the official Rohm Semiconductor datasheet.

The high-speed switching capability of these diodes makes them suitable for high-frequency applications where efficiency is critical. The compact package allows for dense board layouts.
