The S3-0R01F1 is a precision current sense resistor manufactured by Riedon. This resistor is designed for high current applications requiring accurate current measurement. Its low resistance value and high power rating make it suitable for use in power supplies, motor control systems, and other applications where precise current sensing is essential for performance and safety.

Applications

• Power supplies and voltage regulation modules
• Motor control systems
• Battery management systems (BMS)
• Inverters and converters
• Overcurrent protection circuits

Features

• Low resistance value (0.01 Ohms) for minimal voltage drop
• High power rating for handling significant current loads
• Four-terminal Kelvin connection for accurate measurement
• Metal strip construction for high stability and reliability
• RoHS compliant

Benefits

• Accurate current sensing allows for precise control and monitoring of circuits
• Minimal voltage drop reduces power loss and improves efficiency
• High power rating ensures reliable performance in demanding applications
• Four-terminal connection eliminates lead resistance errors
• Robust construction provides long-term stability

Additional Details

The S3 series resistors from Riedon feature a four-terminal Kelvin connection, which allows for accurate current measurement by eliminating the effects of lead resistance. The metal strip construction provides excellent long-term stability and resistance to environmental factors. These resistors are commonly used in applications where precise current measurement is required for control, protection, or monitoring purposes. The low resistance value minimizes power loss and voltage drop, improving overall system efficiency. The high power rating allows for operation at high current levels without overheating. They are also lead-free and RoHS compliant.
