RF2420

Name: RF2420
Brand: RF Micro Devices
SKU: 293368
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	RF2420
Manufacturer	RF Micro Devices
Catalog	Coaxial Connectors (RF)
Description	CONN N PLUG STR 50OHM CRIMP
Datasheet	RF2420 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Connectors, Interconnects
Manufacturer	Amphenol RF Division
Packaging	Bulk
Status	Active
Connector Style	N Type
Connector Type	Plug, Male Pin
Contact Termination	Crimp or Solder
Shield Termination	Crimp
Impedance	50 Ohm
Mounting	Free Hanging (In-Line)
Cable Group	LMR-240
Fastening Type	Threaded
Maximum Input Frequency	11GHz
Housing Color	Silver
Ingress Protection	Weatherproof
Includes	4 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Insulator
Body Material	Brass
Body Finish	White Bronze
Center Contact Plating	Gold
Dielectric Material	Polytetrafluoroethylene (PTFE)
Temperature Range - Operating	-65°C to 165°C
Center Contact Material	Brass
Voltage Rating	1500V
Mating Cycles	500
Insertion Loss	0.15dB
Win Source Part Number	293368-RF2420
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian RF2420 CAD Model

Alternative Products

Description

The Amphenol RF Division RF2420 is a threaded plug male pin N type connector that is designed for use in various electronic applications.

Voltage Rating: 1500V
Temperature: -65°C to 165°C
Impedance: 50 Ohm
Insertion Loss: 0.15dB
Connector Style: N Type
Connector Termination: crimp or solder
Weatherproof: weatherproof
Housing Color: silver
Mounting: free-hanging (in-line)
Mounting Feature: -
Material: brass
Body Finish: white bronze
Center Contact Material: brass
Center Contact Plating: gold
Dielectric Material: Polytetrafluoroethylene (PTFE)
Mating Cycle: 500
Supplied In: bulk
Includes: 4 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Insulator
