RAC04-12SA/277 Recom Power
Same model may have multiple batches, images only for reference.

RAC04-12SA/277

Part No RAC04-12SA/277
Manufacturer Recom Power
Catalog PMIC - Voltage Regulators - Linear + Switching
Description AC/DC CONVERTER 12V 4W  /  Enclosed AC DC Converters 1 Output 12V 333mA 90 ~ 305 VAC Input
Datasheet
RAC04-12SA/277 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>AC DC Converters
Mfr Recom Power
Series POWERLINE RAC04 (4W)
Package Box
Product Status Not For New Designs
Type Enclosed
Number of Outputs 1
Voltage - Input 90 ~ 305 VAC
Voltage - Output 1 12V
Current - Output (Max) 333mA
Power (Watts) 4 W
Applications ITE (Commercial)
Features Universal Input
Temperature Range - Operating -40°C ~ 70°C (With Derating)
Efficiency 77%
Mounting Type Through Hole
Package / Case 7-DIP Module, 6 Leads
Dimension 1.44" L x 1.07" W x 0.69" H (36.7mm x 27.0mm x 17.6mm)
Approval Agency CE, cULus, EN
Standard Number 60950-1
Line Regulation ±0.2%
Load Regulation ±0.5%
Weight 0.058 lb (26.31 g)
Base Product Number RAC04-12
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Other Names 21000097,945-1067,RAC0412SA/277,RAC0412SA277
Standard Package 12
Win Source Part Number 1164998-RAC04-12SA/277
Ultra Librarian 3D Model Ultra Librarian RAC04-12SA/277 CAD Model

Description

The RAC04 (4W) series is an enclosed type AC-DC converter that has universal input features.

  • Type: Enclosed
  • Applications: ITE (Commercial)
  • Model: RAC04-12SA/277
  • Power Rating: 4 W
  • Input Voltage: 90 ~ 305 VAC
  • Output: Single
  • Maximum Output Current: 333mA
  • Output Voltage: 12V
  • Efficiency: 77%
  • Mounting Type: Through-Hole
  • Package/Case: 7-DIP Module, 6 Leads
  • Operating Temperature Range: -40°C to 70°C (With Derating)
