The PE-65508 is a compact Ethernet pulse transformer, typically used in 10/100 Base-T applications. Manufactured by Pulse Electronics, it provides the necessary electrical isolation and impedance matching required between the Ethernet PHY and the network cable. This ensures signal integrity and protects the connected devices from voltage surges and electrical noise. This transformer is a critical component for reliable Ethernet communication in a variety of networking devices.

Applications

• 10/100 Base-T Ethernet network interfaces
• Network Interface Cards (NICs)
• Ethernet Switches and Routers
• Embedded Ethernet controllers
• Industrial Ethernet equipment

Features

• Designed for 10/100 Base-T Ethernet applications
• Provides galvanic isolation between Ethernet PHY and cable
• Offers impedance matching for optimal signal transmission
• Compact size for space-constrained applications
• Compliant with IEEE 802.3 standards

Benefits

• Enhances signal integrity, ensuring reliable data transmission
• Protects Ethernet PHY from voltage surges and electrical noise
• Reduces electromagnetic interference (EMI)
• Simplifies PCB layout and reduces board space requirements
• Improves overall system reliability and longevity

Specifications

The PE-65508 typically features an inductance of around 350 μH, a turns ratio of 1CT:1CT, and an isolation voltage of 1500 Vrms. The operating temperature range generally falls between 0°C to 70°C. Detailed specifications, including pinout diagrams and electrical characteristics, can be found in the official datasheet provided by Pulse Electronics. Its compact size makes it suitable for dense board layouts. Compliance with IEEE 802.3 standards ensures interoperability with other Ethernet devices. The transformer's primary function is to provide electrical isolation and impedance matching for optimal signal transfer in 10/100 Base-T Ethernet systems.
