Same model may have multiple batches, images only for reference.
SMT-1220-TW-R PUI Audio, Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

SMT-1220-TW-R

Part No SMT-1220-TW-R
Manufacturer PUI Audio, Inc.
Catalog Alarms, Buzzers, and Sirens
Description BUZZER MAGNETIC 3V 12MM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Driver Circuitry Transducer, Externally Driven
Input Type Zero-Peak Signal
Voltage - Rated 3 V
Voltage Range 2 ~ 5V
Frequency 2kHz
Technology Electromechanical/Magnetic
Operating Mode Single Tone
Sound Pressure Level (SPL) 80dB @ 3V, 10cm
Current - Supply 35mA
Port Location Top
Temperature Range - Operating -40°C ~ 85°C
Ratings Washable
Mounting Type Surface Mount
Termination Solder Pads
Size / Dimension 0.472" Dia (12.00mm)
Height - Seated (Max) 0.374\
Package Tray
Supply and Demand Status Limited
Win Source Part Number 1547344-SMT-1220-TW-R
Ultra Librarian 3D Model Ultra Librarian SMT-1220-TW-R CAD Model

Description

N
