The PTVSHC2EN5VB is a transient voltage suppressor (TVS) diode array manufactured by Prisemi. This device is specifically designed to protect sensitive electronic circuits from damage caused by electrostatic discharge (ESD) and other transient voltage events. By integrating multiple TVS diodes into a single package, the PTVSHC2EN5VB provides comprehensive protection for multi-line interfaces while minimizing board space requirements. It features a low clamping voltage, fast response time, and high surge capability, making it suitable for a wide range of applications.

Applications

• USB port protection
• HDMI port protection
• Ethernet port protection
• Data line protection in portable devices
• General I/O protection in electronic systems

Features

• TVS diode array: Integrates multiple TVS diodes for multi-line protection.
• Low clamping voltage: Minimizes voltage stress on protected components during transient events.
• Fast response time: Quickly clamps transient voltages to protect downstream circuitry.
• Small package size: Enables compact PCB designs and efficient use of board space.
• High ESD protection capability: Provides robust protection against electrostatic discharge events.
• RoHS compliant: Meets environmental standards for hazardous substances.

Benefits

• Comprehensive multi-line protection: Protects multiple lines simultaneously from ESD and transient voltage threats.
• Enhanced system reliability: Reduces the risk of component failure due to overvoltage events.
• Space savings on PCB: Integrates multiple components into a single package, minimizing board space requirements.
• Simplified circuit design: Reduces component count and simplifies the layout process.
• Cost-effective protection solution: Offers a cost-effective means of protecting sensitive electronic circuits.

Additional Details

The PTVSHC2EN5VB features a standoff voltage of 5V. The clamping voltage is typically around 7.5V at a specified test current, providing a low clamping voltage to safeguard downstream components. The device is designed to withstand multiple ESD strikes without performance degradation. It is available in a compact surface-mount package, facilitating easy integration into existing circuit designs. The operating temperature range is -55°C to +125°C. This TVS diode array offers a reliable and efficient solution for protecting sensitive electronic circuits from ESD and transient voltage events.
