TNY180PG Power Integrations
Same model may have multiple batches, images only for reference.

TNY180PG

Part No TNY180PG
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description 28.5 W (85-265 VAC) 36.5 W (230 / Converter Offline Flyback, Secondary Side SR Topology 132kHz 8-PDIP-C
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - AC DC Converters, Offline Switches
Mfr Power Integrations
Package Tube
Product Status Obsolete
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 650V
Topology Flyback, Secondary Side SR
Duty Cycle 65%
Frequency - Switching 132kHz
Power (Watts) 36.5 W
Fault Protection Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit
Control Features EN
Temperature Range - Operating -40°C ~ 150°C (TJ)
Package / Case 8-DIP (0.300", 7.62mm), 7 Leads
Supplier Device Package 8-PDIP-C
Mounting Type Through Hole
Base Product Number TNY180
Standard Package 50 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 840786-TNY180PG
Ultra Librarian 3D Model Ultra Librarian TNY180PG CAD Model

Description

The Power Integrations 840786-TNY180PG is a power management integrated circuit (IC) designed for AC-DC converters and offline switches.

  • Power Rating: 36.5 watts
  • Output: isolated output
  • Switches: internal switches
  • Breakdown Voltage: 650V
  • Topology: flyback and secondary side SR
  • Duty Cycle: 65%
  • Switching Frequency: 132kHz
  • Fault Protection: current limiting, over load, over temperature, over voltage, and short circuit protection
  • Mounting: through hole
  • Package: 8-DIP
  • Leads: 7
  • Status: active
  • Description: With its active status and reliable performance, the Power Integrations 840786-TNY180PG is a suitable choice for power management applications.
