LNK501GN Real Image LNK501GN real image12292
Same model may have multiple batches, images only for reference.
LNK501GN Real Image LNK501GN real image12292
LNK501GN Real Image LNK501GN real image12292
Same model may have multiple batches, images only for reference.

LNK501GN

Part No LNK501GN
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description Energy Efficient, CV/CC Switcher for Very Low Cost Chargers and Adapters | IC SWIT OCP CV/CC HV 8SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Tube
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Flyback
Duty Cycle 77%
Switching Frequency 30kHz ~ 42kHz
Power (W) 5.5W
Fault Protection Current Limiting, Open Loop, Over Temperature, Short Circuit
Temperature Range - Operating -40°C ~ 150°C
Manufacturer Package 8-SMD (7 Leads), Gull Wing
Supplier Device Package SMD-8B
Mounting Style SMT
Manufacturer Pack Quantity 50
MSL Level 4 (72 Hours)
Win Source Part Number 1202670-LNK501GN
Manufacturer Homepage www.powerint.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LNK501GN CAD Model

Description

The Power Integrations LNK501GN is an isolated integrated circuit with an output power of 5.5W and a switching frequency of 30kHz ~ 42kHz.

  • Output Power: 5.5W
  • Switching Frequency: 30kHz ~ 42kHz
  • Topology: Flyback
  • Duty Cycle: 77 percent
  • Internal Switches: Yes
  • Fault Protections: Current Limiting, Open Loop, Over Temperature, Short Circuit
  • Mounting: SMD-8B package
  • Breakdown Voltage: 700V
  • Market Status: Active
  • Package Quantity: 50 pieces
  • MSL Level: 4 (72 hours)
