LNK500GN-TL Real Image LNK500GN-TL real image10435
Same model may have multiple batches, images only for reference.
LNK500GN-TL Real Image LNK500GN-TL real image10435
LNK500GN-TL Real Image LNK500GN-TL real image10435
Same model may have multiple batches, images only for reference.

LNK500GN-TL

Part No LNK500GN-TL
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC SWIT OCP CV/CC HV 8SMD
Datasheet
LNK500GN-TL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Reel - TR
Status Not For New Designs
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Flyback
Duty Cycle 77%
Frequency - Switching 30kHz to 42kHz
Power (Watts) 5.5W
Fault Protection Current Limiting, Open Loop, Over Temperature, Short Circuit
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package SMD-8B
Mounting Surface Mount
Win Source Part Number 1055989-LNK500GN-TL
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LNK500GN-TL CAD Model

Description

The LNK500GN-TL is an isolated flyback topology product manufactured by Power Integrations.

  • Power: 5.5W
  • Duty Cycle: 77%
  • Voltage Breakdown: 700V
  • Frequency Switching: from 30kHz to 42kHz
  • Fault Protection: current limiting, open loop, over temperature, and short circuit
  • Package: reel
  • Mounting: surface mount
  • Supply and Demand Status: limited
