LNK305DN-TL

Part No LNK305DN-TL
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWIT OCP 8SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Reel - TR
Status Active
Output Isolation Non-Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Buck, Buck-Boost, Flyback
Duty Cycle 69%
Frequency - Switching 66kHz
Fault Protection Current Limiting, Open Loop, Over Temperature, Short Circuit
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package SO-8C
Mounting Surface Mount
Win Source Part Number 132451-LNK305DN-TL
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name LNK305
Introduction Date September 02, 2004
ECCN EAR99
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian LNK305DN-TL CAD Model

Description

The LNK305DN-TL is a non-isolated IC and has a voltage breakdown of 700V and a switching frequency of 66kHz. It also has internal switches and fault protection, making it a reliable component for a variety of applications.

  • Supply and Demand Status: Limited
  • Switches: Internal
  • Fault Protection: Included
  • Switching Frequency: 66kHz
  • Duty Cycle: 69%
  • Package: SO-8C
  • EOL Date: 2022
  • Usage: Common-used part
