LNK304PN Real Image LNK304PN real image
Same model may have multiple batches, images only for reference.
LNK304PN Real Image LNK304PN real image
LNK304PN Real Image LNK304PN real image
Same model may have multiple batches, images only for reference.

LNK304PN

Part No LNK304PN
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWIT OCP 8DIP
Datasheet
LNK304PN Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Tube/Rail
Status Active
Output Isolation Non-Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Buck, Buck-Boost, Flyback
Duty Cycle 69%
Frequency - Switching 66kHz
Fault Protection Current Limiting, Open Loop, Over Temperature, Short Circuit
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package DIP-8B
Mounting Through Hole
Win Source Part Number 019716-LNK304PN
Family Name LNK304
Introduction Date September 02, 2004
ECCN EAR99
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian LNK304PN CAD Model

Description

The LNK304PN from Power Integrations is a non-isolated integrated circuit that operates in buck, buck-boost, and flyback topologies.

  • Breakdown Voltage: 700V
  • Duty Cycle: 69%
  • Switching Frequency: 66kHz
  • Case: DIP-8B
  • Fault Protection Features: Current limiting, open loop, over temperature, short circuit
  • Popularity: High
  • Supply and Demand Status: Balanced
  • Alternative Parts: VIPER17HN, VIPER17LN, LNK304P
  • EOL Date: 2022
