1858785

Name: 1858785
Brand: Phoenix Contact
SKU: 1332210
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	1858785
Manufacturer	Phoenix Contact
Catalog	Headers, Plugs and Sockets
Description	TERM BLOCK PLUG 4POS STR 7.62MM / 4 Position Terminal Block Plug, Female Sockets 0.300" (7.62mm) 180° Free Hanging (In-Line)
Datasheet	1858785 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects>Terminal Blocks>Headers, Plugs and Sockets
Manufacturer	Phoenix Contact
Packaging	Bulk
Type	Plug, Female Sockets
Number of Positions	4
Positions Per Level	4
Number of Levels	1
Pitch	0.300" (7.62mm)
Plug Wire Entry	180°
Termination Style	Screw - Rising Cage Clamp
Mounting	Free Hanging (In-Line)
Current - IEC	12A
Voltage - IEC	1 kV
Current - UL	15 A
Voltage - UL	300 V
Wire Gauge or Range - AWG	12-30 AWG
Wire Gauge or Range - mm2	0.2-2.5mm2
Color	Green
Contact Mating Finish	Tin
Features	Mating Flange
Material Flammability Rating	UL94 V-0
Screw Size	M3
Torque - Screw	0.5-0.6 Nm (4.4-5.3 Lb-In)
Wire Strip Length	7mm
Housing Material	Polyamide (PA), Nylon
Insulation Height	0.591" (15.00mm)
RoHS Status	RoHS Compliant
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8536.69.8000
Other Part Number	1858785-ND,GMSTB2,5/4-STF-7,62,GMSTB 2,5/ 4-STF-7,62,277-6806
Standard Package	50
Win Source Part Number	1332210-1858785
Ultra Librarian 3D Model	Ultra Librarian 1858785 CAD Model

Description

The Phoenix Contact 1332210-1858785 is a 4-position, plug female socket terminal block that is designed for free hanging (in-line) applications.

Positions: 4
Application: Free hanging (in-line)
Pitch: 7.62mm
Wire Gauges: 12-30 AWG
Housing Material: Polyamide (PA) or nylon
Color: Green
Packaging: Bulk
Standard Package: 50
Wire Termination: Screw-rising cage clamp
Voltage: 300V
Current: 15A
