PMV6-5R-L Panduit Corp – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

PMV6-5R-L

Part No PMV6-5R-L
Manufacturer Panduit Corp
Catalog Terminals
Description CONN RING CIRC 10-12AWG M5 CRIMP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Terminal Type Circular
Stud/Tab Size M5 Stud
Thickness 0.040" (1.02mm)
Width - Outer Edges 0.374" (9.50mm)
Length - Overall 1.067" (27.10mm)
Mounting Type Free Hanging (In-Line)
Termination Crimp
Wire Gauge 10-12 AWG
Insulation Insulated
Features Brazed Seam, Serrated Termination
Color Yellow
Contact Material Copper
Contact Finish Tin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1534655-PMV6-5R-L
Ultra Librarian 3D Model Ultra Librarian PMV6-5R-L CAD Model
